Fig.400A FM4-6904-000 1 READER ASSEMBLY ADF/FAX model MF4500
Series
Fig.400A FM4-6949-000 1 READER ASSEMBLY ADF/FAX model MF4400
Series
Fig.400A FM4-6950-000 1 READER ASSEMBLY ADF model MF4400 Series
1 FC7-3630-000 1 BELT, TIMING
2 FK3-1153-000 1 CONTACT IMAGE SENSOR ASS'Y
3 FK3-1154-000 1 CABLE, FLAT, SCNT-OP FAX model
3 FK3-1157-000 1 CABLE, FLAT, SCNT-OP EXCEPT FAX model
4 FK3-1160-000 1 CABLE, FLAT, SCNT-OP
5 FL2-8496-000 1 COPYBOARD GLASS ASS'Y
6 FL3-5062-000 1 IDLER PULLEY HOLDER ASS'Y
7 FM4-6916-000 1 CIS DRIVE MOTOR ASS'Y
8 XA9-0476-000 4 SCREW,TP M3X8
9 FC0-1945-000 2 SPACER, CIS
